PLASTIC REFRACTORIES
Ready-to-use rammable plastic refractory for burner blocks, patching and monolithic linings
PRODUCT OVERVIEW
Plastic refractories are stiff, putty-like mixes supplied ready to install — rammed or pneumatically gunned into place and then dried in service. Phosphate-bonded high-alumina grades develop strength rapidly on heating and give excellent volume stability around complex shapes. They are ideal for burner blocks, kiln nose rings, patching and any lining around tubes or irregular geometry where casting is impractical. CUMI supplies clay, high-alumina and SiC plastic grades.
KEY PROPERTIES
Al₂O₃ Range
45 – 90%
Max Service Temp
1400 – 1800°C
Bulk Density (fired)
2.2 – 2.7 g/cc
Bond Type
Phosphate / air-setting
Installation
Ramming / gunning — ready to use
Volume Stability
Excellent
APPLICATIONS
TECHNICAL SPECIFICATIONS
| Grade | Al₂O₃ | Bulk Density | CCS | Max Temp |
|---|---|---|---|---|
| Clay Plastic | 42-48% | 2.2 g/cc | 30 MPa | 1400°C |
| HA-70 Plastic | 68-72% | 2.5 g/cc | 50 MPa | 1700°C |
| HA-80 Plastic | 78-82% | 2.7 g/cc | 70 MPa | 1800°C |
* Test conditions: IS 1528 (India) / ASTM C-133 / EN 1402. Values are typical — exact data sheets available on request.
AVAILABLE GRADES
INSTALLATION NOTES
- 1
Supplied ready to use — do not add water to phosphate-bonded grades
- 2
Ram in 25–50 mm layers with a pneumatic rammer; key into anchors for vertical/overhead work
- 3
Cut vent holes for moisture/volatile escape before heat-up
- 4
Controlled dry-out: 30°C/hr to 350°C with holds; phosphate bond develops strength on first firing
WHY BUY FROM SHANKER AGENCIES
Shanker Agencies supplies CUMI plastic refractories in clay, high-alumina and SiC grades, with guidance on anchor layout and dry-out for burner blocks and patch repairs.
PARTNER BRANDS
FREQUENTLY ASKED QUESTIONS
A plastic refractory is a stiff, putty-like refractory mix supplied ready to install — you ram or gun it into place and dry it in service, rather than casting it. Phosphate-bonded high-alumina grades develop strength quickly on heating and hold their shape around complex geometry, making them ideal for burner blocks, patching and linings around tubes.
